Interactive entertainment device controller

Define human coordinates and control an interactive entertainment device
  • Control of internal and external device temperature
  • Control 12 ultrasonic distance sensors to locate a person around the device
  • The device can be extended to 16 and ultrasonic sensors
  • 3D communication to send human coordinates and temperature data
  • The coordinates are determined with an accuracy of 5 cm at a distance of 2 meters
  • Emergency shutdown of the executive device if the permissible ambient temperature values are exceeded
  • Operation in the temperature range from -40 to +70 degrees Celsius
ELMANK portfolio - Interactive entertainment device controller
Works done:
  • analysis of possible solutions for processing data from ultrasonic distance sensors
  • development of the device circuitry, including analogue and digital parts
  • simulation simulation of the analog part of the circuit, processing signals from sensors
  • PCB trace
  • adjusting the analog part of the device to ensure stable operation in a wide range of temperatures from -40 to +70 degrees Celsius
  • programming the microcontroller under conditions of restrictions on the communication interface with the interactive device
