Interface converter Profibus DP

Providing two-way communication via Profibus DP (Slave) interface with the control device
  • Full support of interface work with the use of specialized chips Profichip
  • Executive device control via 4-20mA interface and discrete signals
  • Built-in data logging in non-volatile memory
  • Potential decoupling of 2kV signals
  • Operating temperature range -40...+80 degrees
  • Supply Voltage - 12 - 36V DC
ELMANK portfolio - Interface converter Profibus DP
Works done:
  • Device schematic design
  • PCB trace
  • Firmware development
  • Development of a diagnostic and adjustment stand for the device using Siemens industrial controllers
  • Adjustment of the device to ensure stable operation in a wide range of temperatures
  • Development of configuration files (GSD) for correct device detection in industrial automation system
  • Device integration in the control system network of industrial facilities
  • Serial assembly of equipment
