Resonant LLC DC-DC converter

Powerful DC voltage converter
Used in charging stations and DC power supplies
ELMANK portfolio - Glonass-GPS module
Parameters:
  • Rated output power: 10kW
  • Adjustable output voltage range 200-500V
  • Maximum output current value 20A
  • Input voltage rating: 800V midpoint
  • Support of Constant current (CC mode) and Constant voltage (CV) modes of operation throughout the range
  • Potential isolation (up to 2.5kV)
  • Efficiency factor value (COP) of 98%
  • Cooling mode - active (air)
  • Operating ambient temperature range of -20 to 45 °C
  • Software-hardware protection by current and output voltage
